ホーム / 医療機器および注入ポンプ用の18650 11.1V 10000mAh 3S4P リチウムイオンバッテリーパック
This 18650 11.1V 10000mAh 3S4P lithium-ion battery pack provides stable, long-lasting power for infusion pumps, patient monitors, diagnostic equipment, and other medical devices. Its integrated protection circuit helps prevent overcharge, over-discharge, overcurrent, and short circuits. Compact, rechargeable, and customizable, it supports reliable operation in hospitals, clinics, emergency care, and home healthcare applications worldwide.
- モデル: 18650-3S4P
- セル寸法: 18× 65 mm
- 公称電圧:11.1V
- 放電電流: 30 A
- 収容人数: 10000 mAh
- 内部抵抗:120 mΩ
- 応用: Medical Devices and Infusion Pumps
- 充電電圧:12.6 V
無料見積もりを取得
製品リストに戻る
概要
The 18650 11.1V 10000mAh 3S4P lithium-ion battery pack provides reliable and long-lasting power for medical devices, infusion pumps, portable monitors, diagnostic equipment, and other healthcare applications. Built with twelve high-quality 18650 cells arranged in a 3-series, 4-parallel configuration, it delivers stable voltage, high capacity, and consistent discharge performance. The integrated protection circuit helps prevent overcharging, over-discharging, overcurrent, and short circuits, supporting safer operation in demanding medical environments. Its compact design allows flexible installation inside portable or backup-powered equipment, while the durable outer wrap protects the cells from daily wear. The battery pack can be customized with different connectors, wire lengths, protection boards, casing options, and communication functions to match specific device requirements. With dependable runtime, rechargeable convenience, and OEM/ODM customization support, this 11.1V 10000mAh battery pack is a practical power solution for manufacturers developing efficient, mobile, and reliable medical equipment for hospitals, clinics, emergency care, and home healthcare use worldwide.
製品詳細
- High Capacity: The 11.1V 10000mAh capacity provides extended operating time for portable medical equipment.
- 3S4P Configuration: Twelve 18650 cells deliver stable voltage, reliable output, and consistent discharge performance.
- Multiple Protection: The integrated BMS protects against overcharge, over-discharge, overcurrent, and short circuits.
- 充電式設計: High-quality lithium-ion cells support repeated charging and dependable long-term use.
- Compact Construction: The space-efficient battery pack is suitable for installation inside portable medical devices.
- カスタマイズ可能なオプション: Voltage, capacity, connectors, wire length, casing, BMS, and communication functions can be customized.
応用分野
- Infusion pumps and syringe pumps
- Portable patient monitoring systems
- 医療診断機器
- Emergency and first-aid devices
- Portable respiratory equipment
- Home healthcare devices
- Mobile medical instruments
- Backup power systems for clinical equipment
技術的パラメータ
| モデル | 18650 -3S4P |
| セルサイズ | 18 × 65 mm |
| 放電電流 | 30 A |
| 公称電圧 | 7.7V |
| 収容人数 | 10000mAh |
| 内部抵抗 | 120 mΩ |
| 加工方法 | 必要に応じてカスタマイズ |
| 応用 | Medical Devices and Infusion Pumps |
| 充電電圧 | 12.6 V |
